Описание
| Параметр | Значение |
|---|---|
| Housing Model: | DF-T |
| Housing Size: | 0120 |
| Element Model: | DF-T |
| Element Size: | Size 0050 |
| Element Type: | DF-T |
| Connection Type: | G 1/2 |
| Flow Rate Nominal (Air): | 50 m3/h |
| Differential Pressure Gauge: | Economizer |
| Drain Type: | KA 1/2 |
| Maximum Operating Pressure: | 16 Бар(232 Фунты/кв. дюйм) |
| Максимальная рабочая температура: | 65 C(149 F) |
| Minimum Operating Temperature: | 1 C(34 F) |
| Filter Housing Material: | Алюминий |
| Housing Gasket Material: | Perbunan |
| Длина: | 107 Миллиметры(4.21 Дюймы) |
| Ширина: | 103 Миллиметры(4.06 Дюймы) |
| Высота: | 341 Миллиметры(13.43 Дюймы) |
| Масса: | 1 Кг(2.20 Фунты) |
| Drain Connection: | G 1/2 |
| PED 2014/68/EU: | Yes |
| EAC: | Yes |
